Request a quote to find the right shear for your machine.
Contact Connect Work Tools today for pricing, specifications and dealer availability.
Learn about every feature and options that we have to offer
| Model | Carrier Weight | Approx. Shear Weight | Jaw Opening | Jaw Depth | Flow Rate | Max Pressure | Rotate Flow Rate |
|---|---|---|---|---|---|---|---|
| lbs. | lbs. | in. | in. | GPM | PSI | ||
| CS7* (SSL) | 6,600 (min.) | 1,704 | 11.6 | 12.6 | 25 | 4300 | 4 GPM 12/24 VDC |
| CS7* | 15,000 – 22,000 | 1.633 | 11.6 | 12.6 | 25 | 4300 | 4 GPM 12/24 VDC |
| CS15 | 26,000 – 40,000 | 3,860 | 16.1 | 16.1 | 45 | 5000 | 5 GPM |
*The CS7 model comes standard with a 12VDC electric rotation control. Optional 24VDC or hydraulic rotation controls are available for this model.
The CS15 has hydraulic rotation controls.
Weights listed include a standard flat-top mounting bracket.
Unique tip design covers the entire tip reducing maintenance downtime
Massive pivot group eliminates the need for an auto-guide system
360o continuous rotation on a turntable bearing
Maximized power to weight ratio
Made with high-strength, abrasion-resistant steel for durability
Taller blades resulting in a stronger jaw structure
Increased operator visibility with an integrated end cap and nut
Compact main solid main shaft design
Ask us about our new Connect 1 Telematics Device – revolutionary wireless telematics device that gives you detailed diagnostic data on the attachment it’s connected to.
