Discover the CG Series Grapples, complete with full rotation, perfect for industrial demolition, recycling tasks, and site cleanup. These grapples feature a robust design that ensures straightforward maintenance with bolt-on cutting edges. Additionally, optional brackets produced at Connect Work Tools are available for your convenience.
Learn about every feature and options that we have to offer
| Model | Working Weight (lbs) | Carrier Weight (lbs) | Capacity (ft3) | Oil Flow (gpm) | Jaw Width Closed (in) | Max Jaw Opening (in) | Height Closed (in) | Height Opened (in) | Tine Width (in) |
|---|---|---|---|---|---|---|---|---|---|
| CG10 | 1,080 | 10,000 – 18,000 | 7.1 | 16 | 38 | 63 | 40 | 35 | 18.8 |
| CG15 | 2340 | 18,000 – 38,000 | 14.2 | 21 | 42 | 65 | 50 | 44 | 33.5 |
| CG22 | 3,420 | 38,000 – 60,000 | 24.7 | 26 | 48 | 78 | 55 | 49 | 41.3 |
| CG30 | 4,800 | 60,000 – 85,000 | 35.3 | 40 | 58 | 80 | 58 | 65 | 43.9 |
| CG40 | 5,200 | 85,000 – 100,000 | 40.1 | 55 | 62 | 84 | 66 | 58 | 52.1 |
Durable Design
Ask us about our new Connect 1 Telematics Device – revolutionary wireless telematics device that gives you detailed diagnostic data on the attachment it’s connected to.
